Keyboard Controls
Numbered Items Function
1. LED Lamps Shows status of DVR operation.
2. USB Firmware Port Firmware upgrade by connecting PC with latest firmware to USB port.
3. Camera selection & PTZ camera control a. Pressing this button will display a full screen image of that camera.
b. Control PTZ camera (Each button is assigned for each PTZ command).
ON: LIGHT ON SET: SET PRESET
OFF: LIGHT OFF CLEAR: CLEAR PRESET
OPEN: IRIS OPEN GOTO: GOTO PRESET
CLOSE: IRIS CLOSE AUTO: AUTO SCAN
NEAR: FOCUS NEAR F1: USER MACRO 1
FAR: FOCUS FAR F2: USER MACRO 2
WIDE: ZOOM IN F3: USER MACRO 3
TELE: ZOOM OUT F4: USER MACRO 4
4. Record /Playback
REC
Alarm Record Mode/Emergency Record at continuous, Best Quality - Maximum Frame Rate.
STOP Stops Alarm Record Mode and returns DVR to Schedule Record or stops Playback and returns to Schedule
Record Mode.
PLAY Playback of recorded images on HDD.
SEARCH Search for recorded images on HDD.
5. SETUP
MENU
Set up for SYSTEM MENU or use to exit the previous sub-menu.
ENTER Selects each menu option.
NEXT Move to next step.
Navigate in the menu.
+ / _ Reduce or increase the option value in the menu.
6. LIVE Display Controls PTZ On/Off for PAN/TILT/ZOOM control mode
Press this button first to control PTZ camera connected to DVR unit via RS-485
ZOOM Zooming an image
FRZ Freezing an image
MODE Switch to split display MODE button changes screen-division from (to)
full screen to (from) 16-split screen.
PIP Display in PIP (Picture in Picture) mode
SEQ Auto camera image sequencing in full screen mode
K.LOCK Lock the key function. To unlock, press longer time (for several
seconds) and then input the password.
Q. Play (Quick Play) Play from image recorded 2 minutes ago in forward
direction. (in case recorded in continuous mode).
7. Jog Shuttle Enable J/SHUTTLE Pressing Jog Shuttle button (Ready for use Jog/Shuttle)
In playback mode, pressing J. SHUTTLE button make images frozen.
RUN LED on: While you operate Jog or Shuttle
ACTIVE LED on: When J. SHUTTLE button is pressed
8. Jog Shuttle Very easy and convenient search: Press J. Shuttle button, and images in playback pause,
and then Jog and Shuttle makes it very easy and convenient to search, forward or
backward, fast and slow, as user want.
