Specification
Specifications
• Best picture quality (JPEG-2000)
• Real time live display in all channels
• 4 channel video 120(100)ips recording capability
• Triplex (Playback/Recording/Ethernet)
• Multi-language menu
• Convenient search function with Jog/shuttle
• USB port for firmware upgrades
• Easy PTZ camera control by pre-assigned buttons
• Password Protection
• Remote monitoring and download through network
STORAGE CAPACITY Internal HDD, up to 2 HDDs with no limitiation on capacity
Future support for CD-RW For backup (can be replaced by 3rd HDD)
VIDEO I/F Input Composite 4ch
Output Composite 2ch (Monitor/VCR)
Loop Out 4ch
Compression JPEG 2000
Compression Rate User Definable (1/1 ~ 1/999); 1/1 = real time, 1/2 = half real time etc...
Image Size Fixed Basic, Normal, Enhanced, Fine, Super Fine
Display Speed Real Time
RECORDING/SEARCH Recording Mode Scheduled, Motion, Alarm
Search Event Search, Date/Time Search, Jog/Shuttle Search
Recording Speed (NTSC/PAL) Full (60/50), Dual (120/100), Quad (240/200)
Recording Resolution (NTSC/PAL) Full (720 x 240/720 x 288), Dual (360 x 240/360 x 288), Quad (360 x 120/360 x 144)
MULTI-LANGUAGE English, Spanish, German, Italian, French
SWITCHING INTERVAL 1~99 sec selectable
MULTI-SCREEN DISPLAY OPTIONS 4 Way, 6 Way, 8 Way, PIP
Digital Zoom, Freeze Function available in Live Mode, PIP
ALARM Inputs 4 Alarms (NO/NC selectable in SETUP menu)
Outputs 1 (NO/NC)
Post Alarm Duration of alarm output: 1 sec~99 sec selectable
MOTION DETECTION Area Division 16 x 12
Detection Division 32 x 24
NETWORK Ethernet (TCP/IP), Remote Viewer Program included
BACKUP VCR, CD-RW Back-up, Downloaded via IP Network
PTZ CONTROL RS-485, Key Control (Key Assigned for each PTZ Command)
FIRMWARE UPGRADE USB Port for Firmware Upgrade, CD-R
SERIAL I/F RS-485 For PTZ Camera Control
RS-232C For operation using keyboard of PC
POWER REQUIREMENTS 12VDC 5A Adapter
WEIGHT 8.5kg
DIMENSIONS (W/H/D) 436 x 396 x 88mm
