Machine specifications – Southbend METAL-CUTTING BANDSAW SB1019 User Manual
Page 6
-4-
For Machines Mfg. Since 8/09
Model SB1019
I N T R O D U C T I O N
Machine Specifications
Model SB1019
7" x 8" Swivel Mast Metal-Cutting Bandsaw
Product Dimensions:
Weight ..........................................................................................................................................................................481 lbs.
Length/Width/Height ............................................................................................................................. 51
1
⁄
4
" x 29
5
⁄
8
" x 60
5
⁄
8
"
Foot Print (Length/Width) .................................................................................................................................... 51
1
⁄
4
x 25
5
⁄
8
"
Space Required for Full Range of Movement (Length/Width/Height) ....................................................... 59" x 47" x 67
3
⁄
8
"
Shipping Dimensions:
Type ................................................................................................................................................................ Wood Slat Crate
Weight ...........................................................................................................................................................................558 lbs.
Length/Width/Height ....................................................................................................................................... 52" x 30" x 61"
Electrical:
Required Power Source .................................................................................................. 110V or 220V, Single-Phase, 60 Hz
Switch .................................................................................................................................................. Safety ON/OFF Switch
Switch Voltage .................................................................................................................................................................. 110V
Cord Length ..................................................................................................................................................................... 7
1
⁄
2
ft.
Cord Gauge .................................................................................................................................................................14 gauge
Minimum Circuit Size ......................................................................................................20 Amps @110V, 15 Amps @ 220V
Plug Included .......................................................................................................................................................................Yes
Included Plug Type .................................................................................................................................NEMA 5-15 for 110V
Recommended Plug Type for 220V .......................................................................................................................NEMA 6-15
Motors:
Main
Type ............................................................................................................................TEFC Capacitor Start Induction
Horsepower ........................................................................................................................................................... 1
1
⁄
2
HP
Voltage ............................................................................................................................................................110V/220V
Phase .......................................................................................................................................................... Single-Phase
Amps ....................................................................................................................................................................... 18/9A
Speed ............................................................................................................................................................... 1725 RPM
Cycle .......................................................................................................................................................................60 Hz
Number Of Speeds .........................................................................................................................................................1
Pre-Wired ................................................................................................................................................................ 110V
Power Transfer ................................................................................................................................ Sealed Worm Gear
Bearings ................................................................................................................... Shielded and Permanently Sealed
Main Specifications:
Operation Information
Head Swivel....................................................................................................................................................... 45 to 45.
Blade Speeds .................................................................................................................................... 135, 197, 256 FPM
Std. Blade Length ...................................................................................................................................................... 93"
Blade Size Range .........................................................................................................................................................
3
⁄
4
"
Model SB1019
Page 1 of 2
P.O. Box 2027, Bellingham, WA 98227 U.S.A.
PHONE: (360) 734-1540 •
© South Bend Lathe Co.
www.southbendlathe.com
Machine Specifications
