Shure M267 - Manual (Page 8)

9
REPLACEMENT PARTS LIST
REFERENCE
DESIGNATION PART
NUMBER
DESCRIPTION
COMMERCIAL
ALTERNATE
C101,C209,
C219, C227,
C232 86T628 Capacitor, Electrolytic, 5 µ F, 25V Sprague TVA 1303
C115 86L628 Capacitor, Electrolytic, 250 µ F, 50V Sprague
501D227F063PR
C201, C204-
C205, C208 86V628 Capacitor, Electrolytic, 22
µ
F, 6.3V Sprague
501D226F016LL
C210 86M630 Capacitor, Electrolytic, 10
µ
F, 25V Sprague TE 1204
C212-C213 86R630 Capacitor, Electrolytic, 68 µ F, 25V Sprague
501D686F025MN
C215, C218 86L626 Capacitor, Electrolytic, 470
µ
F, 35V Sprague
503D477F035QE
C216, C222 86A630 Capacitor, Electrolytic, 5
µ
F, 35V Sprague TE1303
C221, C229 86N630 Capacitor, Electrolytic, 22
µ
F, 35V Mallory F226KM
C223 86S628 Capacitor, Electrolytic, 1 µ F, 50V Sprague TVA1300
D209,
D211-D214,
D222-D223,
D226-D229 86A415 Diode, Silicon, Computer, 75V TI 1N4148
D210, D217,
D230-D235 86A404 Silicon Rectifier, 100V, 1/2A Motorola 1N4002
D218-D221 86A405 Diode, Germanium, 30V RCA 1N48, 1N60
D301 86F422 Diode, Light-Emitting General Instrument
MV5075C
F201 80F159 Fuse, Slow–Blow, 3AG, 0.1A, 250V Littlefuse 313000 Se-
ries
F202 80C380 Fuse, Time Lag, 0.05A, 250V Schurter 034.3104
J1 95C450 Jack, Phono Switchcraft 3511A
J2A, B 90T2600 Connectors, Binding Post None
J101-J104 95B8011 Connector, 3-Pin Female XLR Switchcraft Y3FDPC
J105 95B8012 Connector, 3-Pin Male XLR Switchcraft Y3MPC
J301 90BJ2600 Phone Jack Switchcraft L-1128PC
L101-L113 80A365 Ferrite Bead Ring Panasonic
Exc-ELSA35
M1 RKC170
(95A8214) Meter, 190 µ A None
MP1-MP5 90A8028 Knob, MIC 1-4, MASTER None
MP6 90A8029 Knobs, PHONE None
MP7 90A8027 Cover, Battery None
MP8-MP9 65A8008 End Cap None
REFERENCE
DESIGNATION PART
NUMBER
DESCRIPTION
COMMERCIAL
ALTERNATE
PL301-PL302 95A8010 Lamp, 6.3V, 0.2A Sylvania 86
Q201 86A350 Transistor, NPN Motorola 2N5210
Q202, Q204 86A334 Transistor, NPN Rohm TIS92
Q203, Q205 86A348 Transistor, PNP Motorola 2N5087
Q206 86A335 Transistor, PNP Rohm TIS93
Q207 86A8302 Transistor, PNP Motorola TIP30A
R250 46A8016 Potentiometer, 100k None
R302, R306,
R310, R314 46B8000 Potentiometer, 100k None
R317 46C8000 Potentiometer, 200k None
R322 46D8000 Potentiometer, 5k None
S101-S104 55B8008 Switch, Slide, 3PDT None
S105, S302, S306 55B8007 Switch, Slide, DPDT None
S106-S107, S301,
S303-S305 55B8001 Switch, Slide, DPDT None
S201 55A8035 Switch, Slide, DPDT Switchcraft EPS1-PC1
S307 90CB2600 Switch, Pushbutton, SPDT Switchcraft 953
S308 55A8009 Switch, Slide, 3PDT None
T201-T204 95B8165 Transformer, Input None
T205 51E235A Transformer, Output None
T206 51A8021 Transformer, Power None
U201 86B808A Integrated Circuit, Quad Op Ampl
(Selected for NF) Raytheon RC4156N
U202 86A8908 Opto-Isolator None
U203 86A811A Integrated Circuit, Dual Op Ampl Raytheon RC4559NB
U204 86A806A Integrated Circuit, Quad Comparator Raytheon LM339DB
U205 86A811A Integrated Circuit, Dual Op Ampl Raytheon RC4559NB
U206 86A803 Integrated Circuit, Dual Op Ampl Motorola MC1458C-P1
U207 86B8930 Integrated Circuit, Voltage Regulator National Semiconductor
LM317AT
W1 90A8045 Line Cord, AC None
Parts listed as RKC Kits should be ordered by that kit number.
