System overview – Samsung SCC-3000 User Manual
Page 6
《6》
System Overview
※ Please refer to page 39 for the detailed connection map of the JUNCTION Box, Controllers and external devices.
(1) General Connection
: Controller Connection Cable
: RS-485/422
: Video Cable
DVR
Dome Camera + DVR: 255 max.
Dome Camera
Dome Camera
Dome Camera
SVR-1630: 255 max.
CCD Camera
Remarks
Junction Box
