Using the IR receiver
Depending on the speaker layout (i.e. when placing the surround speaker (L) toward the listening
position, etc.), or when there is an obstruction, such as a person or object between the IR transmitter
and the IR receiver of the surround speaker (L), you can use the external IR receiver (supplied) instead.
The IR receiver is compact and easy to install.
To connect the IR receiver
Connect the cord of the IR receiver to the DIR-R3 jack of the surround speaker (L).
Notes
• After connecting, the IR receiver is activated and the IR receiver of the surround speaker (L) is not activated
automatically.
• When using the IR receiver, install it following the guidelines of the IR receiver of the surround speaker (L).
POWER
DIR-R3
IR receiver
