Replace or Install a Drive Accessing the Drives
April 2013 Drive Installation or Replacement—Spectra T200, T380, T680, T950, and T-Finity Library
12
Accessing the Drives
This section describes how to access the tape drives.
Spectra T200 or T380 Remove the rear panel cover (if present) in order to
install or replace drives.
1. Using your fingers or a #2 Phillips screwdriver, loosen the two knurled
screws securing the bottom of the cover to either side of the chassis.
2. Lift the cover upward and away from the chassis to disengage the two
nuts extending from the back of the cover from the holes on either side
of the chassis. Set the cover aside.
Figure 4 The rear panel cover and screws (T380 shown).
Figure 5 Cover alignment nuts (one on each side).
Cover
Knurled
screw
Alignment nut
