72
GB
FM tuner section
Tuning range
87.5 - 108.0 MHz
Antenna
FM wire antenna
Antenna terminals
75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Antenna
Loop antenna
Intermediate frequency
450 kHz
3)
You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. While holding down PRESET
TUNING +, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the
procedure.
General
Power requirements
Power output (DIGITAL MEDIA PORT)
DC OUT:
5 V, 700 mA MAX
Power consumption
Power consumption (during standby mode)
0.3 W (When “CONTROL
FOR HDMI” in VIDEO
menu is set to “CTRL
OFF”)
Dimensions (w/h/d) (Approx.)
430 Ч 66.7 Ч 333 mm
(17 Ч 2 3/4 Ч 13 1/8 inches)
including projecting parts
and controls
Mass (Approx.)
3.5 kg (7 lb 12 oz)
Speaker section
HT-SF2300 only
• Front speaker (SS-MSP23F)
• Surround speaker (SS-SRP23F)
• Center speaker (SS-CNP23)
Front/Center speaker
Full range, Magnetically
shielded
Surround speaker
Full range
Speaker unit
Front/Surround speaker
65 mm (2 5/8 inches),
cone type
Center speaker
30 × 60 mm
(1 3/16 × 2 3/8 inches),
cone type
Enclosure type
Front/Surround speaker
Bass reflex
Center speaker
Acoustic suspension
Rated Impedance
3 ohms
Dimension (w/h/d) (Approx.)
Front speaker
113 Ч 830 Ч 83 mm
(4 1/2 Ч 32 3/4 Ч 3 3/8
inches) (without stand)
315 Ч 1,015 - 1,345 Ч 315
mm (12 1/2 Ч 40 - 53 Ч
12 1/2 inches) (with stand)
Area code
Tuning scale
10 kHz step
9 kHz step
U, UC, CA, AU
530 –
1,710 kHz
3)
531 –
1,710 kHz
3)
TW, TH
530 –
1,610 kHz
3)
531 –
1,602 kHz
3)
CEL, CEK
–
531 –
1,602 kHz
Area code
Power requirements
U, UC, CA
120 V AC, 60 Hz
CEL, CEK
230 V AC, 50/60 Hz
AU
240 V AC, 50 Hz
TW
110 V AC, 60 Hz
TH
220 – 230 V AC, 50/60 Hz
Area code
Power consumption
U, CEL, CEK, AU,
TW
165 W
UC, CA
165 W (for USA)
245 VA (for CANADA)
TH
140 W
