General
Certification CE EMC, FCC CLASS A, UL
Electrical
Input Voltage 18 to 30 VAC; 24 VAC nominal, built-in power-line surge
Power Requirement 24 VAC/VDC 850mA
Power Consumption Maximum 20W
Alarm Output 4 Normal relays 24 VDC/1A Max (selectable NC/NO)
Alarm Input 8 Normal dry contact (selectable NC/NO)
Control RS-485/422 baud rate: 2400 ~230k bps (default:9600bps)
Access Time 0.75 second maximum preset recall time
ID (Camera Address) 999 (Factory mode selectable over 999 camera)
Mechanical
Dimension See Figure 10
Weight Approx 1.2 kg
Pan Angle 360 ° continuous rotation
Speed 0.1 ° to 90°/sec. (proportional to zoom)
360 °/sec. maximum (with CTRL/PGM key pressed)
Preset Speed : 380 °/sec
Repeatability 0.2 °
Flip Rotate 180 ° at bottom of tilt
Autoscan 8 auto scan include vector scan.
Preset Position 240 positions with camera status (16-character title)
Tour 8 tours
Pattern Four patterns, 240 second
On-Screen Display Displays camera ID and area name on screen
Environment
Operating temperature 0 °C to 50°C (32°F to 122(F)
Operating humidity 0 to 90%RH (non-condensing)
Storage temperature -20 °C to 60°C (4°F to 140°F)
Specifications are subject to change without notice.
Figure 10– Dimension
