Operating controls of the EK 2015 receiver
Operating controls LC display panel
³ Headphone output (HI), 3.5 mm jack socket
· Output for hearing aids (LOW), 2.5 mm jack
socket
» Antenna
¿ Red LED for battery status and missing trans-
mitter RF signal indication
´ Green LED for audio signal indication
² Charging contacts
¶ SET button
º ̆
/
̄ rocker button (UP/DOWN)
¾ Battery compartment
µ Battery compartment cover
¸ Unlocking button
¹ ON / OFF button with ESC function
Ƹ Internal microphone
ƹ LC display
ቢ Alphanumeric display
ባ 5-step level display for received audio signal
(FM)
ቤ 5-step display for microphone level (MIC)
of internal microphone (only with switched-on
internal microphone)
ብ Lock mode icon (lock mode is activated)
ቦ 4-step battery status display
ቧ 5-step level display for received RF signal
Note:
Depending on the individual configuration of
your receiver, some of the displays shown here
may not appear on the display panel.
³ ·
ቢ
¿
¶
²
¹
¾
µ
º
¸
´
»
ብ ቦ ባ ቤ ቧ
Ƹ
ƹ
