Specifications
2015 Mikroport® System
RF characteristics
Modulation
FM mono
Frequency ranges
518–554, 626–662, 740–776, 786–822, 830–866 MHz
Transmission/receiving frequencies
8 channel banks with up to 20 factory-preset channels each
1 channel banks with up to 20 freely selectable channels
(1,440 frequencies, tunable in steps of 25 kHz)
Switching bandwidth
36 MHz
Nominal/peak deviation
±24 kHz / ±48 kHz
AF characteristics
Noise reduction system
Sennheiser
HDX
AF frequency response
80–16,000 Hz
Signal-to-noise ratio (at 1 mV, peak
deviation)
96 dB(A)
THD (at nominal deviation, 1 kHz)
≤ 0.3 %
General data
Temperature range
–10 °C to +55 °C
Dimensions of system case
(H x W x D)
9.8 x 8.1 x 6.9 inches
Weight of system case (equipped)
approx. 5.7 lbs.
CE Certificate of Conformity
see last page
