Page 3
3
Figure 2
Antenna Connector
The connector is a standard Reverse SMA jack. Simply
connect it to a 2.0dBi, 50 Ohms impedance dipole antenna
to support 2.4 GHz frequency. (The Antenna is changeable
for high gain Antenna), see Figure 2.
RS-232 (Serial)
Connect the RS-232 port into the device as you would
with any computer and serial device, see Figure 3.
Figure 3: RS-232
Power Jack
Antenna
Connector
LEDs
