Sanyo SC-X2100P - Manual (Page 5)

Key
No.
Key
No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:B-476T/B-475(BLUE),N3-78(GRAY),N5-28(WHITE),N1-233(GRAY),NN-B(BLACK)
1 663 000 9963 POWER BRUSH COMP. KEYNO(2-54) 1 51 663 000 9079 SCREW 2
2 663 000 8621 CASE CUSHION 1 52 663 001 0044 CORD ASSEMBLY 1
3 663 000 8638 SWITCH ORNAMENT 1 53 663 000 9093 CORD BUSHING (NN-B) 1
4 663 000 8645 CASE UPPER (B-476T) 1 54 663 000 9109 CAUTION LABEL 1
5 663 000 8652 BUMPER (B-475) 1
6 663 000 8669 LENS (N3-78) 1
7 663 000 8676 CAUTION LABEL C 1
8 663 000 8683 POLYURETHANE FORM 1
9 663 000 8690 SCREW 2
10 663 000 8706 TORSION SPRING 1
11 663 000 9970 SWITCH BUTTON (N1-233) 1
12 663 000 8720 SWITCH SPRING 1
13 663 000 8737 MOVABLE REED (NN-B) 1
14 663 000 8744 MOVABLE REED BASE (NN-B) 1
15 663 000 8751 SCREW 2
16 663 000 3398 LAMP (15W 120V) 1
17 663 000 8768 LAMP HOLDER ASSEMBLY 1
18 663 000 8775 SCREW 7
19 663 000 8782 ROTARY PIPE COVER (N5-23) 1
20 663 000 8799 SHIELD SHEET 1
21 663 000 8805 CAUTION LABEL B 1
22 663 000 7587 ROTARY BRUSH COMP. 1
23 663 000 8812 BEARING HOLDER CAP 2
24 663 000 8829 BELT 1
25 663 000 8836 ROTARY SEAL C 2
26 663 000 8843 ROTARY SEAL B 2
27 663 000 9987 CASE COVER (N1-233) 1
28 663 000 0700 WIRE CONNECTOR (CE-230) 3
29 663 000 8867 CORD ASSEMBLY (WHITE) L=115 1
30 663 000 8874 LEAD WIRE (BLACK) L=130 1
31 663 000 8881 MICRO SWITCH 1
32 663 000 9994 SWITCH HOLDER (N1-233) 1
33 663 000 8904 STEEL BALL 1
34 663 000 8911 HELICAL SPRING 1
35 663 000 8928 SWITCH LEVER ASSEMBLY 1
36 663 000 8263 SCREW (3X12) 2
37 663 000 8935 SWITCH ASSEMBLY A 1
38 663 001 0006 SWITCH BRACKET (N1-233) 1
39 663 000 8959 ROTARY SEAL A 2
40 663 000 8966 CORD ASSEMBLY (BLACK) L=75 1
41 663 000 8973 ARM HOLDER 2
42 663 001 0013 ARM (N1-233) 1
43 663 001 0020 CORD INLET COVER (N1-233) 1
44 663 000 9000 SCREW 3
45 663 000 9017 AC MOTOR (AC 120V) 1
46 663 001 0037 CASE LOWER (N1-233) 1
47 663 000 9031 WHEEL REAR (NN-B) 2
48 663 000 9048 WHEEL FRONT (NN-B) 2
49 663 000 9055 SHAFT 2
50 663 000 9062 CAUTION LABEL A 1
- 5 -
Parts List
(Attachment)
NOTE : The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-X2100P (U.S.A.)
