Sanyo SC-X2100P - Manual (Page 3)

Key
No.
Key
No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:B-476T/B-475(BLUE),N3-99T(SILVER),N1-233/N1-242(GRAY),NN-B(BLACK)
1 663 000 9130 HANDLE ORNAMENT (N3-99T) 1 54 663 000 9543 MOTOR CUSHION FRONT 1
2 663 000 2957 CRAMP SPRING A 1 55 663 000 9550 MOTOR CUSHION COVER 1
3 663 000 9147 CRAMP LEVER A (B-475) 1 56 663 000 9567 MOTOR CUSHION OUTER 1
4 663 000 9154 SCREW (4X14) 2 57 663 000 9574 AIR INLET PACKING REAR 1
5 663 000 9161 HANDLE (N1-233) 1 58 663 000 9581 AIR INLET (N1-233) 1
6 663 000 9178 CRAMP LEVER UPPER (B-475) 1 59 663 000 9598 PACKING H (N1-233) 1
7 663 000 9185 CRAMP PIECE 1 60 663 000 9604 AIR INLET FILTER 1
8 663 000 9192 CRAMP PIN 1 61 663 000 9611 BRAKE SPRING 1
9 663 000 9208 HELICAL SPRING 1 62 663 000 0236 BRAKE ROLLER ASSEMBLY B 1
10 663 000 9215 DUST BOX ASSEMBLY 1 63 663 000 9628 BRAKE ARM (N1-233) 1
11 663 000 9222 GEAR A (N1-233) 1 64 663 000 0076 SCREW (4X16) 4
12 663 000 9239 SCREW (4X10) 1 65 663 000 9635 REEL SUPPORTER ASSEMBLY 1
13 663 000 9246 GEAR C (N1-233) 1 66 663 000 9642 CORD REEL COMP. INCL/P.CORD 1
14 663 000 9253 ORNAMENT PLATE (N1-233) 1 67 663 000 8034 POWER CORD (U2) 1
15 663 000 4425 CRAMP SPRING C 1 68 663 000 9659 SCREW 1
16 663 000 9260 CRAMP ASSEMBLY 1 69 663 000 9666 REAR COVER (N1-233) 1
17 663 000 9277 CAUTION LABEL 1 70 663 000 9673 REEL BUTTON (B-476T) 1
18 663 000 9284 GEAR B (N1-233) 1 71 663 000 9680 SWITCH BUTTON (B-476T) 1
19 663 000 2278 SCREW (4X17) 1 72 663 000 9697 HELICAL SPRING 2
20 663 000 9291 PRE FILTER ASSEMBLY (B-475) 1 73 663 000 9703 SWITCH KNOB (B-476T) 1
21 663 000 3695 DUSTER ARM 4 74 663 000 9710 CASE COVER (B-476T) 1
22 663 000 3701 DUSTER HOLDER 1 75 663 000 9727 TRANSMISSION TUBE 1
23 663 000 0847 SCREW (4X16) 31 76 663 000 9734 CASE ORNAMENT (N1-233) 1
24 663 000 9307 DUST FILTER COMP. 1 77 663 000 2896 SWITCH 1
25 663 000 9314 CRAMP SPRING B 1 78 663 000 9741 TOOL COVER (B-476T) 1
26 663 000 9321 CRAMP LEVER B (N1-233) 1 79 663 000 9758 FRONT COVER A (B-476T) 1
27 663 000 9338 PACKING C (N1-233) 1 80 663 000 9765 FRONT COVER B (B-476T) 1
28 663 000 9345 PACKING B (N1-233) 1 81 663 000 9772 CONNECTOR ASSEMBLY 1
29 663 000 9352 DUST FILTER FRAME (N1-233 1 82 663 000 7716 SLIP RING CLEANER 2
30 663 000 9369 PACKING A (N1-233) 1 83 663 000 7709 COLLECTING SHOE 2
31 663 000 9376 DUST FILTER ASSEMBLY (N5-23) 1 84 663 000 9789 BASE HOLDER (N1-233) 1
32 663 000 9383 OUTLET FILTER ASSEMBLY 1 85 663 000 9796 SLIP RING BASE UPPER 1
33 663 000 9390 FILTER FIXTURE B (N1-233) 1 86 663 000 9802 JOINT SPRING 2
34 663 000 9406 AIR SPREADER R 2 87 663 000 9819 SLIP RING BASE LOWER 1
35 663 000 9413 AIR SPREADER S 2 88 663 000 7679 SLIP RING 2
36 663 000 9420 POLYURETHANE FOAM 1 89 663 000 7686 AIR INLET PACKING 1
37 663 000 9437 FILTER FIXTURE A (N1-233) 1 90 663 000 9826 CASE UPPER (N3-99T) 1
38 663 000 9444 PACKING L 1 91 663 000 9833 BYPASS TUBE ASSEMBLY 1
39 663 000 0243 SCREW (4X20) 20 92 663 000 9840 CASE BUMPER (B-475) 1
40 663 000 2872 SCREW (3X10) 6 93 663 000 9857 BYPASS COVER (N1-242) 1
41 663 000 9451 FUSE ASSEMBLY (125V 15A) 1 94 663 000 9864 SCREW 2
42 663 000 9468 CONTROL CIRCUITE ASSEMBLY A 1 95 663 000 0823 CASTER (NN-B) 1
43 663 000 9475 CONTROL CIRCUITE ASSEMBLY B 1 96 663 000 9871 NAME PLATE 1
44 663 000 9482 OUTLET FILTER 1 97 663 000 9888 CORD INLET COVER (N1-233) 1
45 663 000 9499 BRAKE ARM BRACKET (N1-233) 1 98 663 000 9895 CORD INLET COVER SMALL 1
46 663 000 9505 REEL KNOB (N1-233) 1 99 663 000 9901 SUPPLEMENT CASE (N1-233) 1
47 663 000 9512 AIR OUTLET PACKING 1 100 663 000 9918 TRANSMISSION COVER (N1-233) 1
48 663 000 9529 AIR OUTLET (N1-233) 1 101 663 000 3312 TRANSMISSION ASSEMBLY 1
49 663 000 1158 SCREW 1 102 663 000 9925 CASE LOWER BOTTOM (N1-233) 1
50 663 000 1141 MOTOR CUSHION SLEEVE 1 103 663 000 9932 BOTTOM PACKING (N1-233) 1
51 663 000 7884 MOTOR CUSHION REAR 1 104 663 000 9949 WHEEL REAR ASSEMBLY 2
52 663 000 7891 SILENCER PIPE 1 105 663 000 9956 CASE LOWER (N1-233) 1
53 663 000 9536 MOTOR COMP. (AC 120V) 1
663 000 0298 CARBON BRUSH ASSEMBLY 2
- 3 -
Parts List
(Main unit)
NOTE : The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-X2100P (U.S.A.)
