ROUTING SWITCHER SYSTEM (E)
5-1. Setting Items of the Primary Station
EDIT GLOBAL PHANTOM DVS-V6464B V2.10 STATION NUMBER 1
(4094 REMAIN)
0001 GPHA001
LEVEL: 1=VID 2=A1 3=A2 4=4 5=5 6=6 7=7 8=8
OUT001 .... .... .... ....
OUT002 .... .... .... ....
OUT003 .... .... .... ....
OUT004 .... .... .... ....
OUT005 5 .... .... ....
OUT006 5 6 .... ....
OUT007 5 6 7 ....
OUT008 5 6 7 8
OUT009 .... .... .... ....
OUT010 .... .... .... ....
OUT011 .... .... .... ....
OUT012 .... .... .... ....
OUT013 .... .... .... ....
OUT014 .... .... .... ....
OUT015 .... .... .... ....
OUT016 5 .... 7 8
0=IN 1=OUT 2=.... 3=.... 4=.... 5=.... 6=.... 7=....
8=.... 9=.... A=.... B=.... C=.... D=.... E=.... F= GPHA
F1:SEARCH F2:ADD F3:DELETE F4:DstLvl Ctrl-E:RETURN TO LAST MENU
3. As the cursor is placed where the name is typed, press
[Enter]. The input mode will be set.
4. Select the codes assigned to each type name and enter
any number using the cursor. Press [Enter] key to set
it. Press [Ctrl]
_ [P] to delete the phantom name.
5. Move the cursor to the place to input the destination
and press [Enter]. The input mode will be set.
6. Input the destination name with the alphabet or
numerical keys and press [Enter] to set it.
7. Input the source name in the same way as
setting the destination name and press [Enter].
8. Set the crosspoint level. Move the cursor to
desired level and press [Enter]. The setting will be
changed.
Press [Ctrl]
_ [E]. The menu will return.
Example of Global Phantom Edit Screen
Operating Function Keys
(Global Phantom Edit Display)
[F1] : SEARCH (To move the cursor to any source name
or destination name)
n
When menu item [J] is set to the Description name
mode, [F1] (SEARCH) will have the following
functions.
1. When [F1] is pressed, “Please Input NAME =”
will be displayed.
2. Enter the Description name (within seven
characters) from the head.
3. When [Enter] is pressed, the Description name
entered will be searched.
4. If the desired name does not exist in the screen,
press [F1] again.
[F2] : ADD (To add the row of crosspoints to be regis-
tered as the global phantom)
[F3] : DELETE (To delete the crosspoints)
1. Select the destination name to be deleted using
the cursor.
2. Press [F3].
[F4] : Dstlvl (To change the level of the crosspoint at the
cursor to the level set at the menu item [E])
1. Select the destination name to be returned to the
initial level using the cursor.
2. Press [F4].
n
When the name mode of menu item [J] is switched, the
destination and source names displayed on the global
phantom edit screen will change.
