ROUTING SWITCHER SYSTEM (E)
SET TIE LINES DVS-128 V1.00 STATION NUMBER 1
--PATHS 1------------------------------------------------------------------
SOURCE: SOURCE No. DESTINETION No. ROUTE: SOURCE No. DESTINETION No.
L1 0001 - 0010 0009 - 0010 L2 0011 - 0012 0017 - 0018
DESTINATION:SOURCE No. DESTINETION No.
L1 0021 - 0022 0021 - 0030
--PATHS 2------------------------------------------------------------------
SOURCE: SOURCE No. DESTINETION No. ROUTE: SOURCE No. DESTINETION No.
L2 0013 - 0020 0019 - 0020 L. .... - .... .... - ....
DESTINATION:SOURCE No. DESTINETION No.
L1 0023 - 0024 0021 - 0030
1
1
10
10
13
20
9
8
10
17
20
19
18
12 11 13
24 23
25
22 21
25
31
8
1
11
16
21
21
30
30
10
x
10
10
x
10
10
x
10
~
~
~
~
1
LEVEL 1
LEVEL 2
LEVEL 1
31
16
11
20
7-2. Changed Menu (Primary Station Setting Items)
(Example)
An example in which the three matrices of 10
x 10 are used and are connected by the Tie-Line, is shown.
A signal of IN 1-10 and IN 13-20 can be selected from OUT 21-30 in this example.
Example of Setting Screen
