Specifications
Port - Ports 1-15: RJ-45, Twisted-pair, fixed crossover
- Port 16: RJ-45, Twisted-pair, switch-selectable crossover
Weight - 2.1 kg
Internal Switching - 4K entry address table
- Store and forward switching method
- 256 Kbyte Buffer per segment
- Filtering, forwarding and learning network bridging functions
- Line speed forwarding and filtering rates
Ethernet Interface - 10BASE-T: 100 Ohm, EIA/TIA Categories 3,4 or 5 twisted pair
Fast Ethernet Interface - 100BASE-TX: 100 Ohm, EIA/TIA Category 5 twisted pair
LEDS - Power-one
- Partition-one per port
- Link-one per port
- Collision-one per segment
- Activity-one per segment
Stacking Connectors - SCSI-2 ,50 pin
Certification - CE marking
- Safety UL, CSA, TUV/GS
- Emissions FCC Class A, VCCI Class A, CISPR Class A
- Immunity IEC 1000-4-2/3/4/6
Standard - ANSI/IEEE 802.3 Ethernet
- ANSI/IEEE 802.3u fast Ethernet
- ISO/IEC 8802-3 Ethernet
