Page 38: Assembl y
ASSEMBLY
1598 01/11
Assembly Section 3-4
© 2011 Alamo Group Inc.
ASSEMBL
Y
Proper Ballasting and Wheel Spacing
Spread front wheels to maximum distance
allowable without interfering with loader.
Spread rear wheels to maximum distance.
Add rear wheel weight, rear ballast box or
implement. Make sure there is 25% of total weight
on rear axle.
