Samsung ML 2250 TI - Manual (Page 2)

Photo 4
Step 5
Remove the two screws holding the PCR
cleaning brush.
(See Photo 5)
Step 6
Lift out the cleaning brush.
(See Photo 6)
Clean the brush carefully using dry
compressed air.
Step 8
Slide the contact end cap away from the
cartridge.
(See Photo 8)
Photo 7
Photo 8
Need trust-worthy, detailed Technical
Instructions for another engine?
V isit: www.futuregraphicsllc.com
2 ML 2250 Technical Instructions
Photo 5
Photo 6
Step 4
Remove the top section of the cartridge.
(See Photo 4)
Step 7
Remove the four screws holding the
contact end cap to the cartridge.
(See Photo 7)
Notes
