Sony CDX-V58MP User Manual
System up vcd / mp3 player, Csx-v58mp

Precautions
Moisture condensation
On a rainy day or in a very damp area, moisture may
condense on the lenses inside the unit. Should this occur,
the unit will not operate properly. In this case, remove
the disc and wait for about an hour until the
moisture has evaporated.
Notes on discs (1-A)
Do not use discs with sticky residue on the surface (e.g.,
second-hand or rental discs with sticky seals, ink, or
peeling stickers). If you use such a disc, the sticky
residue could cause the disc to stop spinning and may
cause a malfunction or ruin the disc.
• Do not use any discs with labels or stickers
attached.
The following malfunctions may result from
using such discs:
—Inability to eject a disc (due to a label or
sticker peeling off and jamming the eject
mechanism).
—Inability to read audio data correctly (e.g.,
playback skipping, or no playback) due to
heat shrinking of a sticker or label causing a
disc to warp.
•Discs with non-standard shapes (e.g., heart,
square, star) cannot be played on this unit.
Attempting to do so may damage the unit. Do
not use such discs.
•You cannot play 8 cm CDs.
Notes on handling discs (1-B)
A dirty or defective disc may cause sound-
dropouts during playback. To enjoy optimum
sound, handle the disc as follows.
On handling discs
• To keep the disc clean, handle the disc by its edge.
Do not touch the surface (1).
• Do not stick paper or tape on the disc (2).
If there is a sticky residue, glue etc., on the disc,
remove it completely before using the disc.
• Do not expose discs to direct sunlight or heat
sources such as hot air ducts.
Do not leave discs in a car parked in direct
sunlight (3).
• After playing a disc, store it in its case.
On cleaning
• Before playing a disc, clean it with a cleaning
cloth. Wipe the disc from the centre out (4).
Do not use solvents such as benzine, thinner,
commercially available cleaners or antistatic
spray intended for analogue discs.
3-245-176-11
(3)
Operating Instructions
Sony Corporation © 2002
Printed in Korea
CSX-V58MP
System up
VCD/MP3
Player
1
A
Features
•Sony BUS system compatible VCD/MP3
Player.
•MP3 file playback (recorded in the ISO9660
level 1 or 2 format, or Joliet or Romeo in the
expansion format or in Multi Session)
• CD-R/CD-RW which can have a session
added can be played.
• Discs recorded in Multi Session (CD-Extra,
Mixed mode CD, etc.) can be played,
depending on the recording method.
Specifications
System
Compact disc digital audio
system
Signal format system NTSC/PAL switchable
Frequency response
20 – 20,000 Hz
Wow and flutter
Below the measurable limit
Signal-to-noise ratio
85 dB
Outputs
Audio outputs (left/right)
Video output
BUS control output
Power requirement
12 V DC car battery
(negative ground)
Current drain
0.9 A (during disc playback)
1.8 A (during loading or ejecting
a disc)
Operating temperature –10 °C to +55 °C
Dimensions
Approx. 178
Ч 50 Ч 172 mm
(w/h/d)
Mounting Dimensions Approx. 178
Ч 50 Ч 154 mm
(w/h/d)
Mass
Approx. 1.3 kg
Supplied accessories
Parts for installation and
connections (1 set)
Optional equipment
Media Center/Receiver
XAV-7W
Design and specifications are subject to change
without notice.
•
•
•
•
–
1
•
•
•
1
•
1
•
2
•
3
•
•
4
B
1
2
3
4
Discs with sticky residue or ink
Discs with labels attached
Discs with peeling stickers
