Sinclair Super Stripper - Manual (Page 7)

7
8.0 Spare Parts
Super Stripper
Pos # Pieces Description Part #
1 1 Chasis S019700
4 2 Piston Block T016228
6 10 Screw M 8x30 T014736
7 8 Cylindrical pin 8x40 T014876
8 2 Lubricating nipple T014914
9 1 Hood S014657
10 4 Screw M 10x70 T014742
11 9 Safety washer 10 mm T014861
12 2 Bushing 20x26x30 T014910
13 1 Blade holder S014655
14 1 Striking Foot S014660
15 19 Screw M 8x25 T014734
16 4 Countersink screw M 10x25 T014763
17 2 Tension pin 10x20 T014890
18 2 Piston Rod T015132
19 3 Washer M 12 T014830
20 2 Screw soc head M 12x30 T014744
21 2 Connecting Rod Bearing T015417
23 2 Wheel pin T014888
24 6 Washer, 16mm T014831
25 2 Drive Wheel T015135
26 1 Gear mounting right T015031
27 4 Screw M 10x45 T014741
28 2 Screw M 8x30 T014736
29 1 Pin screw M 10x60 T014788
30 1 Gear block T015140
31 1 Drive belt 210 L050 T014938
34 1 Drive shaft 88 S014663
35 2 Nut key 5x5x32 T014902
38 2 Black transport wheel T014954
39 1 Axle wheel S014664
40 1 Nut key 6x6x32 T014904
41 1 Connecting rod 88 S014662
43 1 Small bearing 6206 T014710
44 2 Circlip I62 T014856
45 1 Circlip A17 T014850
46 2 Ball Bearing 6305 T014712
47 2 Circlip A30 T014853
48 1 Excenter Shaft S014661
49 1 Nut key 4x4x20 T014901
50 1 Shaft key 6x6x25 T014903
51 1 Circlip A25 T014852
52 1 Bearing block, right T017079
53 1 Bearing block, left T017079
54 4 Screw m 5x25 T014722
55 4 Safety Ring 5mm T014858
56 1 Motor, 110V T015056
58 1 Motor power cord T014973
