PS Engineering PMA8000-SR with Built-In SIRIUS Satellite Radio - Manual (Page 35)

PS Engineering
PMA8000-SR Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-880-0000 Appendix B Rev. 14, Oct. 2008
Figure 6-1 PMA8000-SR Installation Drawing
Caution: Apply steady pressure to the bezel while screwing the unit into the tray to
ensure even seating of the unit and connectors.
2.00 in
2.38 in
0.54 in
Antenna Coax, 20'
Supplied
Figure 6-2 SIRIUS Antenna Drawing
