4
Operation
MAINTENANCE
Cleaning Clear Tube
To clean the clear tube, wash with warm water and mild
soap or detergent. Use a soft, clean sponge or cloth.
DO NOT use abrasive, alkaline, or petroleum based
cleaners.
Cover
The cover can be rinsed with a hose when dirty. A dirty
cover will inhibit the fast flow of grass clippings into the
cover. Do not leave grass or leaves in the cart for a long
period of time.
The cover is subject to wear and deterioration.
Check the cover frequently. Use an approved
replacement cover.
WARNING
OPERATION
Dumping Grass and Leaves
1. Back the tractor to the desired place for unloading.
Shut the tractor's engine of before getting off the trac-
tor's seat.
2. Unhook the strap from the door lock and raise the
cover assembly to the open position. Lock the cover
in place by hooking the strap to the locking tab
(Figure 1). Also see Figure 2.
3. Move the latch handle to the unlock position and
dump the cart's box using one of the front lift handles.
The connecting sleeve will slide off the discharge
chute and the cart's box will dump at a 90° angle for
quick unloading.
Figure 2. Emptying the Cart
Figure 1. Opening the Cover
Before opening the cover for any reason, engage
the parking brake, shut off the engine, remove
the key, and wait for all moving parts to stop.
WARNING
The maximum weight capacity of the cart is 400
lbs. Do not exceed.
CAUTION
Wheels
Lubricate the wheel assembly before using the cart and
as necessary thereafter. A grease fitting is located at
swivel base. Use multi-purpose lithium grease.
Tires
The tire pressure should be 30 psi.
