6 Pipeline HD Mini Series SATA Product Manual, Rev. E
2.4 Physical organization
Drive model Read/write heads Number of discs
ST9500323CS 4
2
ST9320328CS 3
ST9250311CS
2 1
ST91603110CS
2.5 Recording and interface technology
Interface Serial ATA (SATA)
Recording method Perpendicular
Recording density BPI (bits/inch avg) 1,490k
Track density TPI (tracks/inch avg) 265k
Areal density (Gbits/inch 2 avg) 394
Spindle speed (RPM) ( ± 0.2%) 5,400
Maximum Internal transfer rate (Mbits/sec) 1,175
I/O data-transfer rate (Mbytes/sec max) 300 default / 150 available via Seagate specific SCT command
Interleave 1:1
Cache buffer 8 Mbytes (8,192 kbytes)
2.6 Physical characteristics
Drive specification
Height (mm)
(inches)
9.5 +/-0.2
0.374 +/-0.0078
Width (mm)
(inches)
69.85 +/-0.25
2.75 +/-0.0098
Length (mm)
(inches)
100.35 +0.55 / -0.25
3.957 +0.079 / -0.0098
Weight (max)
ST9500323CS, ST9320328CS,
ST9250311CS, ST91603110CS
110 grams
0.243 pounds
2.7 Seek time
Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using
drive diagnostics. The specifications in the table below are defined as follows:
• Track-to-track seek time is an average of all possible single-track seeks in both directions.
• Average seek time is a true statistical random average of at least 5,000 measurements of seeks between ran-
dom tracks, less overhead.
Table 2: Typical seek times
Seek times (msec) Read
