Southbend SB1017 - Manual (Page 49)

For Machines Mfg. Since 8/09 Model SB1017
-47-
P A R T S
Head Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 PN05 HEX NUT 1/4-20 77-5 PSB1017077-5 BUSHING
3 PW06 FLAT WASHER 1/4 79 PSB1017079 BLADE TENSION KNOB BOLT 3/8-16 X 94
15 PSB1017015 TENSION ROD ASSEMBLY 80 PSB1017080 COMPRESSION SPRING
17 PSB1017017 HEAD PIVOT ROD 81 PSB1017081 HEAD CASTING
19 PSB1017019 WORK STOP BRACKET 90 PSB1017090 TRANSMISSION GEAR ASSEMBLY
20 PSS17 SET SCREW 5/16-18 X 5/16 90-1 PSB1017090-1 REAR BLADE WHEEL AXLE
21 PSB1017021 WORK STOP ROD 90-2 PSB1017090-2 TRANSMISSION GEAR
43 PSB1017043 CORD STRAIN RELIEF 90-3 PRP20M ROLL PIN 4 X 22
45 PSB1017045 RIGHT TENSION ROD BRACKET 90-4 PK23M KEY 5 X 5 X 25
45-1 PSB1017045-1 LEFT TENSION ROD BRACKET 90-5 P6202ZZ BALL BEARING 6202ZZ
46 PSB1017046 SPRING HOOK SCREW 90-6 PSB1017090-6 BUSHING
47 PSB1017047 TENSION SPRING 90-7 PSB1017090-7 OIL SEAL
50 PB07 HEX BOLT 5/16-18 X 3/4 92 PSB1017092 GEARBOX GASKET
51 PW07 FLAT WASHER 5/16 93 PSB1017093 GEARBOX COVER
54 PSB1017054 PIVOT BRACKET 100 PFH37 FLAT HD SCR 8-32 X 3/8
55 PSB1017055 TABLE ASSEMBLY 103 PSB1017103 BLADE TENSION SLIDE ASSEMBLY
55-1 PSB1017055-1 FLAT HD SCR 1/4-20 X 1-2 103-1 PSB1017103-1 SHAFT BLOCK
55-2 PSB1017055-2 TABLE 103-2 PSB1017103-2 BLADE TENSION SLIDE PLATE
55-3 PSB1017055-3 TABLE BRACKET 103-3 PSS38 SET SCREW 5/16-18 X 5/8
55-4 PN05 HEX NUT 1/4-20 103-4 PW07 FLAT WASHER 5/16
59 PSB1017059 REAR SAFETY COVER 103-5 PB12 HEX BOLT 5/16-18 X 1-1/4
59-1 PW06 FLAT WASHER 1/4 104 PB03 HEX BOLT 5/16-18 X 1
59-2 PS07 PHLP HD SCR 1/4-20 X 3/8 109 PSB1017109 BLADE TENSION SLIDE GUIDE
59-3 PSB1017059-3 FRONT SAFETY COVER 113 PSB1017113 BLADE 14TPI 1/2 X 64-1/2"
59-4 PCAP50M CAP SCREW M5-.8 X 10 118 PB19 HEX BOLT 1/4-20 X 1/2
61 PSS38 SET SCREW 5/16-18 X 5/8 120 PSB1017120 BUSHING 19 X 17 X 7
71 PSB1017071 REAR BLADE WHEEL 123 PB31 HEX BOLT 1/4-20 X 1
71-1 PSS17 SET SCREW 5/16-18 X 5/16 189 PW07 FLAT WASHER 5/16
72 PSB1017072 BEARING COVER 198 PR05M EXT RETAINING RING 15MM
73 PK23M KEY 5 X 5 X 25 207 PSB1017207 LOCK PIN
75 PB02 HEX BOLT 1/4-20 X 5/8 208 PSB1017208 LOCK PIN ASSEMBLY
77 PSB1017077 FRONT BLADE WHEEL ASSEMBLY 212 PB03 HEX BOLT 5/16-18 X 1
77-1 PSB1017077-1 FRONT BLADE WHEEL 214 PB02 HEX BOLT 1/4-20 X 5/8
77-2 PSB1017077-2 FRONT BLADE WHEEL AXLE ASSEMBLY 412 PW02 FLAT WASHER 3/8
