Woodstock W1752 User Manual
Page 6
-4-
W1752 Owner's Manual (Mfg. 1/07+)
IN
TR
O
DU
CT
IO
N
Main Specifications
Swing Over Bed ................................................................................... 10"
Swing Over Tool Rest ........................................................................... 7
1
/
2
"
Distance Between Centers ...................................................................... 15"
Spindle Size .............................................................................7
51
/
64
" x 1
7
/
8
"
Spindle TPI ................................................................................. 1" x 8 TPI
Outboard Spindle Size ............................................................................. 1"
Spindle Bore .....................................................................................
23
/
64
"
Spindle Taper ................................................................................... MT#2
Tailstock Taper ................................................................................. MT#2
Tailstock Center .................................................................................... 5"
Number of Spindle Speeds ........................................................................ 6
Range of Spindle Speeds ..............................480, 1270, 1960, 2730, 3327, 4023 RPM
Bed Width ..................................................................................8
3
/
16
" RPM
Faceplate Size ...................................................................................... 3"
Bed Construction ..........................................................................Cast Iron
Frame Construction ...........................................................Cast Iron and Steel
Headstock Construction .......................................................Cast Iron and Steel
Tailstock Construction ........................................................Cast Iron and Steel
Other Specifications
Country Of Origin .............................................................................. China
Warranty ...................................................................................... 2 Years
Serial Number Location ............................................... Data Label on Headstock
Assembly Time ...........................................................................10 Minutes
Sound Rating ...................................................................... Less than 80 dB
Model W1752 Machine Specifications, Page 2 of 2
