SPECIFICATIONS
TV format : Compatible with NTSC TV format
Scanning method : 525 TV lines, 60 fields/sec., 2:1 interlaced
Capturing element : Interline transmission method, 1/3 inch CCD
fixed capturing element
Effective picture element : 379 K (VDC-C2074VA, VDC-C1074VA)
250 K (VDC-C2024V, VDC-C1024V,
VDC-M2024V, VDC-M1024V)
Synchronization method : Internal sync or line lock
Horizontal resolution : 460 TV lines (VDC-C2074VA, VDC-C1074VA)
380 TV lines (VDC-M2024V, VDC-M1024V)
330 TV lines (VDC-C2024V, VDC-C1024V)
Video signal output : 1.0 Vp-p/75 Ω (BNC termination)
S/N ratio : 50 dB (VDC-M2024V, VDC-M1024V
48 dB (VDC-C2074VA, VDC-C1074VA,
VDC-C2024V, VDC-C1024V)
Minimum object
illumination (50IRE) : 0.2 Lux (VDC-M2024V, VDC-M1024V)
2.0 Lux (VDC-C2024V, VDC-C1024V)
3.0 Lux (VDC-C2074VA, VDC-C1074VA)
White balance (color only) : Indoor/outdoor/push lock selectable manually
Backlight compensation
(BLC) function : ON/OFF selectable manually, center focus
separate photometry method
B/W cameras: ON fixed
Backlight compensation
iris level adjustment: : Manual V. R.
Flickerless function: : ON/OFF selectable manually
B/W cameras: None
Gain control: : Selectable manually
Built-in lens: : Variable focal lens F2.0 – 2.8, f= 4 – 8 mm
Manual angle of field
adjustment function : Horizontal (pan) → 360° , Vertical (tilt) → 80°
Drip prevention structure : Simplified
Operating environment : Temperature –10° C – +50° C
Humidity 90% RH or less
Storage environment : Temperature –20° C – +60° C
Humidity 70% RH or less
Power voltage/
Power consumption
(Approx.) : 12 V DC or 24 V AC/60 Hz
2.5 W (VDC-M2024V, VDC-M1024V)
3.5 W (VDC-C2024V, VDC-C1024V)
4.2 W (VDC-C2074VA, VDC-C1074VA)
Weight (Approx.) : 1.45 kg (VDC-M1024V)
1.5 kg (VDC- C1024V, VDC- C1074VA)
1.15 Kg (VDC- M2024V)
1.2 kg (VDC- C2024V, VDC- C2074VA)
Dimensions : Surface type
153.5 (W) x 103.3 (H) mm, Dome 102 mm φ
6.04 (W) x 4.07 (H) inch, Dome 4.02 inch φ
In-ceiling type
153.5 (W) x 121.8 (H) mm, Dome 102 mm
φ
6.04 (W) x 4.80 (H) inch, Dome 4.02 inch φ
