High-performance speed dome camera systems, Outdoor type

background image

Outdoor
housing

36x, Day/Night Camera

36x, Color Camera

30x, Day/Night Camera

30x, Color Camera

Camera type

VCC-9800P/9700P/9600P/9500P

Image compression

Resolution

Picture quality

Frame rate

Audio compression method

Microphone input

Audio output

Bandwidth

Alarm buffer

Interface

Protocols

Simultaneous access capacity

Security

Bundled software

Specifications

VCC-9800P
VCC-9700P
VCC-9600P
VCC-9500P

*DFFC: Dynamic Field/Frame Conversion

Motion detection and field/frame conversion are performed to enhance
the vertical resolution of images with no movement and reduce blurring
of moving objects in images with movement.

Microsoft and Windows are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries. Intel
and Pentium are trademarks or registered trademarks of Intel Corporation
or its subsidiaries in the U.S. and other countries. All other trademarks are
the property of their respective owners.

Note:
• Frame rates are variable dependant upon network line conditions and

PC performance.

• Because products and software described in this brochure are subject

to continuous improvement; SANYO reserves the right to modify
product specifications, functions and design without notice.

• Comparative images are representations only.

High-Performance
Speed Dome Camera
Systems

Caution: Please consult the instruction manual to ensure safe and proper operation of the product.

SANYO Electric Co., Ltd.

www.sanyosecurity.com

©2006 SANYO Printed in Japan ’06.12. MA.

SMS137

DI Company of SANYO Electric Co., Ltd.
obtained Quality Management System
ISO 9001 and Environmental Management
System ISO 14001 certifications.

EC00J0303

051

Distributed by:

JPEG

720 x 572, 720 x 572DFFC*, 720 x 286, 640 x 480, 640 x 480DFFC*,

360 x 286, 180 x 143

5 levels

Max. 25 IPS (720 x 286)

G.711 (192 kbps), full duplex

–62 to –32 dB (monaural microphone) 3.5 mm mini jack

LINE OUT, monaural audio output, Max. –8 dB, 3.5 mm mini jack

128, 256, 512 Kbps, 1, 2, 3, 4 Mbps, no limitation

Up to 8 MB; configurable

10BASE-T/100BASE-TX (RJ45 connector)

TCP, UDP, HTTP, HTTPS, SMTP, NTP, DHCP, FTP, UPnP

Image: Max. 16, Voice: Max. 16 (admin: 1)

BASIC authentication (ID/password), SSL supported (image only)

VA-SW3050LITE

5.1 kg = VCC-9800EXCP/9800EXSP

VCC-9830EXCP/9830EXSP

Model No.

Scanning system
Image sensor
Picture elements
Horizontal resolution

Minimum
illumination
(approx.)

Electronic sensitivity boost
Video S/N ratio
Backlight compensation
White balance
Gain control

Electronic shutter

Zoom lens

Movement
range

Movement
speed

Motion detection

Synchronizing system
Communication
Protocols

Environmental
conditions

Power requirement

Power
consumption
(approx.)

Weight
(approx.)

PAL standard 625 lines, 50 fields/sec.

1/4” (approx. 3.6 x 2.7 mm) interline transfer method CCD

Total: 795(H) x 596(V), Effective: 752(H) x 582(V)

520 TV lines

Auto (interlocked with auto iris), up to 32x / OFF

More than 50 dB (AGC OFF)

Auto focus

Auto / One-push / Manual

Backlight compensation

Centerweighted average metering/multi-spot evaluative metering

Privacy masking

ON / OFF, max. of 24 masked locations (Wide view screen; 1 screen max. 4 masks) All-around privacy masking

Preset positions

256

128

Alarm input/output

External inputs: 8, External outputs: 2, NO (Normal Open)/NC (Normal Closed) switch, Motion detection with external alarm AND/OR output options

Electronic sensitivity boosting

Auto / OFF, works with auto iris, settings up to 32x setting possible

Aperture

H/V setting possible

Day/night operation

Auto / Color / B/W settings

Auto / Color / B/W settings

Iris control

Auto / Manual

ON / OFF, slide SW, ON = Multi-spot photometry (48-section) / 5-section photometry / Multi-spot masking (48-section)

ATW / AWC / Manual / Outdoor / Indoor / Fluorescent

LOW / NORMAL / MID / HIGH / OFF

ON (PRESET, ZONE) / OFF: Motion zoom function

Internal sync. / Line lock (LINE PHASE)

RS-485 / Coaxial control

SANYO, Pelco-D, Other (TBD)

35 to 90% RH

24 V AC, 50Hz or 230 V AC, 50Hz

36x optical zoom, f = 3.4 to 122.4 mm (F1.6 to 4.5)

ON / OFF, up to 16x electronic zoom (Max. 576x combined with optical zoom)

30x optical zoom, f = 3.5 to 105 mm (F1.4 to 3.7)

ON / OFF, up to 16x electronic zoom (Max. 480x combined with optical zoom)

360

°

endless

–5 to 185

°

(digital auto flip ON)

Preset: 435

°

/sec., Manual: 0.1 to 120

°

/sec.

Preset: 400

°

/sec., Manual: 0.1 to 120

°

/sec.

1.0 lx (at F1.6, GAIN: HIGH, color mode)

0.05 lx, (at F1.6, B/W mode)

1.0 lx (at F1.6, GAIN:

HIGH, color mode)

0.8 lx (at F1.4, GAIN: HIGH, color mode)

0.04 lx, (at F1.6, B/W mode)

0.8 lx (at F1.4, GAIN:

HIGH, color mode)

0.4 lx (at F1.6, GAIN: HIGH, color mode)

0.02 lx, (at F1.6, B/W mode)

0.4 lx (at F1.6 GAIN:

HIGH, color mode)

0.32 lx (at F1.4, GAIN: HIGH, color mode)

0.016 lx, (at F1.6, B/W mode)

0.32 lx (at F1.4, GAIN:

HIGH, color mode)

High-speed mode: 8 steps: 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000

Low-speed mode: 5 steps: 2x, 4x, 8x, 16x, 32x (1/25, 1/12, 1/6, 1/3, 1/1.5)

Tilting

Camera unit +
Power supply
base

Panning

Tilting

Panning

–10 to 50

°

C (+14 to 122

°

F), –30 to 50

°

C (–22 to 122

°

F) when the outdoor housing, VA-80EX is used

TBD:
TBD:

Temperature
Humidity

Outdoor types

In-ceiling
types

50 IRE

20 IRE

High-performance cameras that integrate lenses,

motorized drives, control systems and housings with

newly developed cutting-edge technologies to provide

high-precision surveillance matched

to a broad range of applications.

PAL

36x

Optical

zoom

36x

Optical

zoom

PAL

30x

Optical

zoom

PAL

PAL

30x

Optical

zoom

VA-80LAN Optional Network Board

Surface types

Outdoor type

5.1 kg = VCC-9700EXCP/9700EXSP

VCC-9730EXCP/9730EXSP

5.1 kg = VCC-9600EXCP/9600EXSP

VCC-9630EXCP/9630EXSP

5.1 kg = VCC-9500EXCP/9500EXSP

VCC-9530EXCP/9530EXSP

2.4 kg = VCC-9800INP

VCC-9830INP

2.4 kg = VCC-9700INP

VCC-9730INP

2.4 kg = VCC-9600INP

VCC-9630INP

2.4 kg = VCC-9500INP

VCC-9530INP

3.4 kg =

2.7 kg =

VCC-9800EMP
VCC-9830EMP
VCC-9800EFP
VCC-9830EFP

VCC-MC800P + VA-84S
VCC-MC800P + VA-80S

TBD:
TBD:

VCC-MC700P + VA-84S
VCC-MC700P + VA-80S

VCC-MC600P + VA-84S
VCC-MC600P + VA-80S

16 W:
17 W:

VCC-MC500P + VA-84S
VCC-MC500P + VA-80S

16 W:
17 W:

3.4 kg =

2.7 kg =

VCC-9700EMP
VCC-9730EMP
VCC-9700EFP
VCC-9730EFP

3.4 kg =

2.7 kg =

VCC-9600EMP
VCC-9630EMP
VCC-9600EFP
VCC-9630EFP

3.4 kg =

2.7 kg =

VCC-9500EMP
VCC-9530EMP
VCC-9500EFP
VCC-9530EFP

35W: VA-80EX
