Fuel and hydraulic system – Scag Power Equipment STWC User Manual
Page 57
53
Section 8
1
482643
Pump, BDP-10A-316 (L.H.)
482644
Pump, BDP-10A-419 (R.H.)
2
482266-01 Elbow, 90 Degree 9/16 O-Ring x 3/8 Hose
3
48572-02
Fitting, 1/2” JIC x 5/8 O-Ring
4
48811
Hose, 3/8 Pushlock (Specify length)
5
482573
Bushing
6
482574
Fitting
7
482266-01 Elbow, 90 Degree 9/16 O-Ring x 3/8 Hose
8
48136-13
Hose Clamp, .69 Dia.
9
482548
Hose Assembly
10
04060-06
Roll Pin
11
48572-04
Fitting, 1/2” JIC x 1/2” O-Ring
12
48603-06
O-Ring
13
04001-20
Bolt, Hex Head 3/8-16 x 1-1/2”
14
04017-07
Bolt, Hex Head 1/4-20 x 1-1/4”
15
04030-02
Lockwasher
16
04021-09
Nut, Elastic Stop 3/8-16
17
422969
Control Lever
18
04001-08
Bolt, Hex Head 5/16-18 x 3/4”
19
04030-03
Lockwasher, 5/16
20
04040-15
Flatwasher, 5/16-.375 x .875 x .083
21
481164
Cap, Hydraulic Tank
22
481507
Insert, Filler Neck
23
48829
Control Block
24
421203
Clamp Plate
25
461479
Hydraulic Tank Assembly w/fittings
26
48603-06
O-Ring
27
482277
Tee Fitting, O-Ring to Barb
28
48136-13
Clamp, .69 Max. / .25 Min. Dia.
29
482571
Bushing
30
482572
Elbow, 0.38 Hose
31
48136-13
Clamp
Ref. Part
No. No.
Description
Ref. Part
No. No.
Description
FUEL AND HYDRAULIC SYSTEM
32
48058
Fuel Hose, 1/4 ID
33
423912
Bracket Fuel Valve
34
48059-01
Clamp, Fuel Hose 1/4 Hose ID
35
482212
Valve, Fuel Shutoff
36
48136-13
Clamp, .69 Max. / .25 Min. Dia.
37
482266-01 Elbow, 1/4 NTP x 3/8 Hose Barb
38
04019-03
Nut, Serr. Flange 5/16-18
39
04041-07
Flatwasher, 3/8-.391 x .938 x .105
40
48462-01
Oil Filter
41
482798
Filter Head Assembly
42
482539
Fitting, Tee Special
43
48571-02
Cap, 3/4-16 JIC
44
482557
Hose, Filter Inlet
45
461699
Fuel Tank RH
46
482547
Cap, Fuel Tank (incl. item #53)
47
48309
Tank Bushing
48
48939
Elbow, 90 Degree
49
461698
Fuel Tank LH
50
48811
Hose, 3/8 Pushlock 15” Long
51
482708
Cooler, Transmission (61A Only)
52
04010-10
Screw, 1/4-20 x 2”
53
482774
Gasket, Gas Tank Cap
54
**
Fuel Filter
55
482605
Hose Assembly
56
04001-11
Bolt, Hec Head 5/16-18 x 1-1/2
57 482802 Nipple, Oil Filter 1.0-12 UNF-2A x 1-1/4”
58 04001-17 Bolt, Hex Head 5/16-18 x 2”
** Available through the individual engine manufacturer.
-
