i n t e l l i g e n t w i r e l e s s p l a t f o r m

airHaul™ Nexus User Guide

Appendix D – SNMP Trap

The airHaul Nexus generates SNMP trap that can be forwarded to the SNMP Trap server. The

SNMP Trap server IP address is set in section.

The following table provides a list of SNMP traps generated.

Trap

Message

IP address

Object Identifier: 1.3.6.1.4.1.14882.2.1.1 Value: IP address>


IP netmask

Object Identifier: 1.3.6.1.4.1.14882.2.1.2 Value: IP netmask>

Gateway

Object Identifier: 1.3.6.1.4.1.14882.2.1.3 Value: Gateway>

SSID

Object Identifier: 1.3.6.1.4.1.14882.5.1.3.3 Value: SSID>

Radio Mode

Object Identifier: 1.3.6.1.4.1.14882.5.1.18 Value:

Note: Possible values for radio mode are given in the table below.

Value

airHaul

airPoint™

airClient™

0

Remote Router

Router

1

Remote Bridge

Bridge

2

3

Root Bridge

Bridge

4

NAT
