- 22 -
Unbuffered SODIMM
datasheet
DDR3 SDRAM
Rev. 1.0
[ Table 14 ] DDR3-1066 Speed Bins
Speed DDR3-1066
Units NOTE CL-nRCD-nRP 7 - 7 - 7
Parameter Symbol min max
Internal read command to first data tAA 13.125 20 ns
ACT to internal read or write delay time tRCD 13.125 - ns
PRE command period tRP 13.125 - ns
ACT to ACT or REF command period tRC 50.625 - ns
ACT to PRE command period tRAS 37.5 9*tREFI ns
CL = 5
CWL = 5 tCK(AVG) 3.0 3.3 ns 1,2,3,4,5,9,10
CWL = 6 tCK(AVG) Reserved ns 4
CL = 6
CWL = 5 tCK(AVG) 2.5 3.3 ns 1,2,3,5
CWL = 6 tCK(AVG) Reserved ns 1,2,3,4
CL = 7
CWL = 5 tCK(AVG) Reserved ns 4
CWL = 6 tCK(AVG) 1.875 <2.5 ns 1,2,3,4,8
CL = 8
CWL = 5 tCK(AVG) Reserved ns 4
CWL = 6 tCK(AVG) 1.875 <2.5 ns 1,2,3
Supported CL Settings 5, 6,7,8 nCK
Supported CWL Settings 5,6 nCK
