6-4 Drive Bay Installation/Removal
Accessing the Drive Bays
CD-ROM/Serial ATA Drives: For installing or removing the CD-ROM or Serial ATA
drive, you will need to gain access to the inside of the server by removing the top
cover of the chassis.
Note: Only a "slim" CD-ROM will fi t in the 6014L-M.
Serial ATA Drive Installation
The SATA drive is not hot-swappable, meaning system power must be turned off
before installing or removing it. The CD-ROM drive needs to be removed fi rst to
gain access to the hard drive.
To install or remove the hard drive, fi rst power down the system and then remove
the top cover of the chassis as described on page 6-7. Then remove the CD-ROM
drive by removing the two screws that secure it to the chassis (one screw comes
in from the side of the chassis and the other screws straight down into a standoff
through the drive bracket). Disconnect the CD-ROM drive's power and data cables
then lift the CD-ROM drive out of the chassis.
Figure 6-2. System Cooling Fans
