2-4
S UPER S ERVER 6014L-M User's Manual
2-4 Installing the System into a Rack
(Rack hardware optional)
This section provides information on installing the SuperServer 6014L-M into a rack
unit. If the system has already been mounted into a rack, you can skip ahead to
Sections 2-5 and 2-6.
Basic Installation Procedure
The 6014L-M server comes with two rack mounting brackets, which are located on
each side at the front of the chassis. To mount the system into a rack, simply screw
these brackets directly to the front of the rack (two screws for each bracket). As
Figure 2-1 shows, the brackets can be located at the front of the chassis (left fi gure)
or moved approximately one-third to the rear of the chassis (right fi gure).
Figure 2-1. Installing the Server into a Rack: Basic
