19
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Number
Per
Unit
MODEL
Part
Number
Key
Number
Some items are included for illustrative purposes only and in certain instances may not be available.
2
3
Star Manufacturing International, Inc.
Description Model
PARTS LIST
June 22, 2006, Rev. K
14' TWO SIDED GRILLS
29 2V-Z3252 1 PIN ASSY - TOP HOUSING STOP
30 2R-Z2896 1 COUNTERBALANCE -14”-IRON GR14I, GR14IT, GR14C CG14IGT, CG14ITGT,
CG14I, CG14IT
30 2R-Z2897 1 COUNTERBALANCE -14”-ALUM.
31 D9-GR0032 2 TORQUE BOX ASSY.
32 D9-Z3071 4 BRACKET-HANDLE
33 2V-Z3072 2 HANDLE - SIDE
34 D9-GR0034 1 GREASE CABINET ASSY.
34 D9-GR0150 1 GREASE CABINET ASSY. GR14SN
35 D9-GR0215 1 GREASE DRAWER ASSY.
35 D9-GR0157 1 GREASE DRAWER ASSY. GR14SN
37 D9-Z2610 1 BASE BOTTOM - 14”
37 DR-GR0247 1 BASE BOTTOM - 14" 230V MODELS
37 D9-GR0257 1 BASE BOTTOM - 14" ASSY GR14SN
38 2A-Z0314 4 FOOT, 4” GR14I, GR14C GR14IT, CG14I, CG14IT,
CG14IGT, CG14ITGT
38 2A-Z1485 4 FOOT, 1” ADJUSTABLE
38 2A-Z7760 4 FOOT, 1" 1/2" ADJUSTMENT GR14SN
39 D9-GR0061 1 BODY ASSY. - 14”
39 D9-GR0184 1 BODY ASSY GR14SN
40 2J-Z1836 1 TIMER CONTROL CG14T, CG14IT, CG14IGT, GR14T, GR14IT
41 2K-Z1971 4 SPACER CG14T, CG14IT, CG14IGT, GR14T, GR14IT
42 2J-Y6689 1 PILOT LIGHT, 120V CG14, GR14 (120V MODELS)
42 2J-Z2329 1 PILOT LIGHT, 240V GR14I, GR14C CG14IGT, CG14I, CG14,
GR14 (240V MODELS)
43 D9-GR0108 1 FACEPLATE ASSY. - 14” NO TIMER GR14I, CG14IGT, CG14I, CG14, GR14
43 D9-GR0185 1 FACEPLATE ASSY. - 14" GR14SN
43 D9-GR0178 1 FACEPLATE ASSY. - 14” 2 TIMERS CG14-2T
43 D9-GR0210 1 FACEPLATE ASSY. - 14” w/TIMER GR14IT, CG14ITGT, CG14IT, CG14T, GR14T
44 2E-Z6863 1 SWITCH 3 POS CG14T, CG14IT, CG14IGT, GR14T, GR14IT
44 PS-GR0224 1 SWITCH CG14T-120V W/SERIAL NUMBERS BELOW CGC25308
CG14IT-120V W/SERIAL NUMBERS BELOW CGC24701
GR14T-120V W/SERIAL NUMBERS BELOW GRC23789
CG14IT-240V W/SERIAL NUMBERS BELOW CGC24559
45 2M-Z6870 1 OVERLAY - 14” w/TIMER GR14IT, CG14ITGT, CG14IT, CG14T, GR14T
45 2M-Z3050 1 OVERLAY - 14” NO TIMER GR14I, CG14IGT, CG14I, CG14, GR14
45 2M-Z3929 1 OVERLAY - 14" NO TIMER GR14SN
45 2M-Z3816 1 OVERLAY - 14” w/2 MANUAL TIMERS CG14-2T
46 2I-05-07-0013 1 RUBBER BOOT, SWITCH
47 2R-Z4621 1 KNOB-CONTROL
48 2T-6447 1 THERMOSTAT 118V-236V
49 2A-Z3026 1 HALF CLIP
50 D9-Z8082 1 BTM. INSULATION RET. PLT. 14”
51 D9-Z8082 1 BTM ELEMENT RET. PLATE 14”
51 D9-Z9853 1 PLATE BTM. ELEMENT RETAINER GR14C
52 2N-Z1981 1 BTM ELEMENT, HEATING, 1000W/120 CG14, CG14T, GR14, GR14T, CG14IT-120V
52 2N-Z2022 1 BTM ELEMENT, HEATING, 1000W/240 CG14, CG14T, GR14, GR14T
52 2N-Z2392 1 BTM ELEMENT, HEATING, 1800W/240V GR14I, GR14C, GR14IT, CG14IGT, CG14ITGT, CG14I,
CG14IT
53 2F-Z1945 1 CASTING, SM. BOT., ALUM.-14” GR14, GR14T
53 2F-Z1947 1 CASTING, GR. BOT., ALUM.-14” CG14, CG14T
53 2F-Z1949 1 CASTING, SM. BOT., IRON-14” GR14I, GR14IT, CG14IGT, CG14ITGT
53 2F-Z1951 1 CASTING, GR. BOT., IRON-14” CG14I, CG14IT
53 2F-Z9653 1 PLATEN, BTM CHROME SMOOTH 14" GR14C
