Page 18
18
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED
PAGE
INCLUDE MODEL AND SERIAL NUMBER
OF
1
2C-Z2992
2
SCREW,
HANDLE
2
2V-Z2989
1
HANDLE - 14”
2
2V-Z3413
1
HANDLE - 14” S.S.
GR14, GR14T
SER. # GRC00112 - 00138,
GRC00778
-
00858,
GRC00864
-
01256
3
2B-Z2987
2
ARM - 14”
3
2B-Z3336
2
ARM
GR14SN
4
2C-08-07-0040 4
NUT
4
2C-08-07-0262 4
WASHER
5
2C-Z2992
4
SCREW,
ARM
TO
BRACKET
6
D9-Z2036
1
HOUSING-TOP-14”
7
2C-Z3200
2
PIN
-
TOP
HOUSING
8
2C-Z2955
2
RETAINER
RING
9
2C-08-07-0040
2
1/4” NUT, USE PART NUMBER 2C-Z2820
10
2A-Z3827
1
CONDUIT
KEEPER
PLATE
11
2C-Z3780
2
CONDUIT
RETAINER
12
2E-Z2898
1
CONDUIT ASSY. - PTFE
13
2E-Z3768
1
CONDUIT
LOCKNUT
14
D9-04-GR-0166 1
WIRE
MOUNT
15
D9-GR0079
1
TOP RETAINING PLATE AY/14
16
D9-Z2888
2
INSULATION - 14”
17
2A-Z6604
8
SPACER - INSULATED PLATE
17
2A-Z9514
8
SPACER - INSULATED PLATE
GR14C
18
D9-Z2075
1
TOP
ELEMENT/INS.
PLATE/14
18
2F-Z9847
1
ELEMENT PLATE-TOP 14"
GR14C
19
2C-08-07-0285
8
SCREW, ELEMENT RET. PLATE
20
2N-Z1980
1
TOP ELEMENT, HEATING, 800W/120
CG14, CG14T, GR14, GR14T, CG14IT-120V
20
2N-Z2021
1
TOP ELEMENT, HEATING, 800W/240V
CG14, CG14T, GR14, GR14T
20
2N-Z2391
1
TOP ELEMENT, HEATING, 1800W/240
GR14I, GR14IT, GR14C CG14IGT, CG14ITGT,
CG14I,
CG14IT
21
2F-Z7786
1
CASTING, SM. TOP, ALUM.-14”
GR14, GR14T
21
2F-Z1946
1
CASTING, GR. TOP, ALUM.-14”
CG14, CG14T
21
2F-Z1948
1
CASTING, SM. TOP, IRON-14”
GR14I, GR14IT
21
2F-Z1950
1
CASTING, GR. TOP, IRON-14”
CG14IGT, CG14ITGT
21
2F-Z9846
1
TOP ASSY CHROME 14"
GR14C
22
2K-3485
1
BUSHING-HEYCO #SR-9P-2
GR14I, GR14IT, CG14IGT, CG14ITGT, CG14I,
CG14IT
(240V
MODELS)
2K-Y2968
1
BUSHING
7W-2
CG14IT-120V
2K-Y6764
1
BUSHING
CG14IT-120VC
(CANADIAN),
GR14C
2K-Y3240
1
BUSHING
CG14, CG14FT, CG14T, GR14, GR14SN,
GR14T,
(120V
&120VC)
23
2E-Z2905
1
CORD SJTO 12/2 NEMA 6-20P
GR14I, GR14IT, CG14IGT, CG14ITGT, CG14I, GR14C
CG14IT
(240V
MODELS)
2E-Z2935
1
CORD SET 14/3 NEMA 5-15P
120V MODELS
2E-Z4119
1
CORD, POWER 12/3 5-20P
120VC (CANADIAN) MODELS
24
2M-Z2620
1
LABEL CAUTION, BI-LINGUAL
25
2E-05-07-0350 1
TRANSFORMER
230V/10V
6VA
240V
MODELS
25
2E-05-07-0351
1
TRANSFORMER 115/10V 6VA
120V MODELS
26
2E-Z2894
1
TERMINAL
BLOCK
27
D9-GR0054
1
REAR LINER ASSY. - 14”/BOT
CG14, GR14, CG14T, GR14T
27
D9-GR0080
1
REAR LINER ASSY. - 14”/REAR
CG14I, GR14I, CG14IGT, CG14IT, GR14IT, CG14ITGT
27
D9-GR0201
1
REAR
LINER
ASSY.
CG14IT
(120V)
27
D9-GR0132
1
REAR LINER ASSY. - 14"
GR14C
28
2C-1512
2
SCREW - PIN ASSY
Number
Per
Unit
MODEL
Part
Number
Key
Number
Some items are included for illustrative purposes only and in certain instances may not be available.
1
3
Star Manufacturing International, Inc.
Description
Model
PARTS LIST
June 22, 2006, Rev. K
14' TWO SIDED GRILLS
