Star Manufacturing PRO-MAX GR14 - Manual (Page 16)

16
PARTS LIST
June 22, 2006, Rev. K
10' TWO SIDED GRILLS
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description Model
MODEL
Part
Number
Key
Number
Star Manufacturing International, Inc.
1 2C-Z2992 2 SCREW, HANDLE
2 2V-Z2990 1 HANDLE - 10”
3 2B-Z2988 2 ARM - 10”
4 2C-08-07-0040 4 NUT
4 2C-08-07-0262 4 WASHER
5 2C-Z2992 4 SCREW, ARM TO BRACKET
6 D9-Z2038 1 HOUSING-TOP-10”
7 2C-Z3200 2 PIN - TOP HOUSING
8 2C-Z2855 2 RETAINER RING
9 2C-08-07-0040 2 1/4” NUT, USE PART NUMBER 2C-Z2820
10 24-Z3827 1 CONDUIT KEEPER PLATE
11 2C-Z3780 2 CONDUIT RETAINER
12 2E-Z2898 1 CONDUIT ASSY. - PTFE
13 2E-Z3768 1 CONDUIT LOCKNUT
14 D9-04-GR-0166 1 WIRE MOUNT
15 D9-GR0084 1 TOP RETAINING PLATE AY/10
16 D9-Z2908 2 INSULATION - 10”
17 2A-Z6604 8 SPACER - INSULATED PLATE
18 D9-Z2772 1 TOP ELEMENT/INS. PLATE/10
19 2C-08-07-0285 8 SCREW, ELEMENT RET. PLATE
20 2N-Z1978 1 TOP ELEMENT, HEATING, 800W/120 GR10I, GR10IT, CG10I, CG10IT, GR10, GR10T
20 2N-Z2019 1 TOP ELEMENT, HEATING, 800W/240V GR10I, GR10IT, CG10I, CG10IT, GR10, GR10T
21 2F-Z1928 1 CASTING, SM. TOP,ALUM.-10” GR10, GR10T
21 2F-Z1932 1 CASTING, SM. TOP, IRON-10” GR10I, GR10IT
21 2F-Z1934 1 CASTING, GR. TOP, IRON-10” CG10I, CG10IT
22 2K-Y3240 1 BUSHING 90 SR 17-2 GR10, GR10T, GR10I, GR10IT, CG10I, CG10IT,
(120V MODELS),
GR10, GR10T, GR10I, GR10IT, CG10I,CG10IT
(240V MODELS)
23 2E-Z2770 1 CORD, POWER, 14-3, 6-15P GR10T, GR10, GR10I, GR10IT, CG10I, CG10IT,
(240V MODELS)
2E-Z2935 1 CORD SET 14/3 NEMA 5-15P GR10T, GR10, GR10I, GR10IT, CG10I, CG10IT,
(120V MODELS)
2E-Z4119 1 CORD, POWER, 12/3 5-20P 120VC MODELS
24 2M-Z2620 1 LABEL CAUTION, BI-LINGUAL
25 2E-05-07-0350 1 TRANSFORMER 230V/10V 6VA 240V MODELS
25 2E-05-07-0351 1 TRANSFORMER 115/10V 6VA 120V MODELS
26 2E-Z2894 1 TERMINAL BLOCK
27 D9-GR0053 1 REAR LINER ASSY. - 10”/BOT
28 2C-1512 2 SCREW - PIN ASSY
29 2V-Z3252 1 PIN ASSY - TOP HOUSING STOP
30 2R-Z2907 1 COUNTERBALANCE -10”-IRON
30 2R-Z3333 1 COUNTERBALANCE -10”-ALUM.
31 D9-GR0032 2 TORQUE BOX ASSY.
32 D9-Z3071 4 BRACKET-HANDLE
33 2V-Z3072 2 HANDLE - SIDE
34 D9-GR0034 1 GREASE CABINET ASSY.
35 D9-GR0215 1 GREASE DRAWER ASSY
37 D9-Z2711 1 BASE BOTTOM - 10”
D9-GR0246 1 BASE BOTTOM - 10" 230V MODELS
38 2A-Z1485 4 FOOT, 1” ADJUSTABLE
1
