14
B A
C D
GREEN
BLACK
WHITE
15 AMP PLUG
NEMA 5-15P ON ALL 120V UNITS.
NEMA 6-15P ON 240V, 1,800 WATT UNITS.
20 AMP PLUG
NEMA 6-20P ON 240V, 3,600 WATT UNITS.
TOP ELEMENT
TRANSFORMER TERMINAL BLOCK
FOR REFERENCE
WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED
WITH THE BOTTOM PLATE REMOVED. ITEMS ARE IN
GENERAL LOCATION BUT MAY BE RELOCATED OR SCALED
FOR CLARITY.
3
E2 E1
8
8
1
1
11
12
12
11
5
2
5 2
4
4
10
10
9
9
13
13
3
3 7
6
6
7
INDICATOR LIGHT
(POWER ON)
TIMER BOARD SWITCH
THERMOSTAT
BOTTOM ELEMENT
230V UNITS
INLET IEC 320 16A
20
19 18
L N
G
MODEL: CG/GR, 10/14, 120V/230/240V,
WITH TIMER
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR MANUFACTURING INTERNATIONAL INC.
SK2001 Rev A 8/10/2004
