Back panel
21
Back panel
The back panel contains ports and jacks for supplied and optional cables.
Network media receiver (back panel)
1
Optical OUT port
Supports the digital optical input of an audio device.
2
S-video jack
Connection for an S-video cable.
3
Video jack
Connection for a video cable.
4
Audio L jack
Connection for an audio cable.
5
Audio R jack
Connection for an audio cable.
6
Ethernet port
Connection for a 100BASE-TX Ethernet cable (RJ-45).
