PowerSaver (When used as a Network LCD Display)
State
Normal Oper-
ation
Power saving
mode
Power off
(Power-but-
ton)
Power off
(Power-
switch)
Power Indicator
On
Blinking
On
Off
Power
Consump-
tion
320MXn-
2
200 W
Less than 5 W
5 W
0 W
PowerSaver (When used as a normal LCD Display)
State
Normal Oper-
ation
Power saving
mode
Power off
(Power-but-
ton)
Power off
(Power-
switch)
Power Indicator
On
Blinking
On
Blinking
Power
Consump-
tion
320MX-2
130 W
Less than 2 W
1 W
0 W
Preset Timing Modes
If the signal transferred from the computer is the same as the following Preset Timing Modes,
the screen will be adjusted automatically. However, if the signal differs, the screen may go
blank while the power LED is on. Refer to the video card manual and adjusts the screen as
follows.
Display Mode
Horizontal
Frequency
(kHz)
Vertical Fre-
quency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
Specifications
IBM，640 x 350
31.469
70.086
25.175
+/-
IBM，640 x 480
31.469
59.940
25.175
-/-
IBM，720 x 400
31.469
70.087
28.322
-/+
MAC，640 x 480
35.000
66.667
30.240
-/-
MAC，832 x 624
49.726
74.551
57.284
-/-
MAC，1152 x 870
68.681
75.062
100.000
-/-
VESA，640 x 480
37.861
72.809
31.500
-/-
VESA，640 x 480
37.500
75.000
31.500
-/-
VESA，800 x 600
35.156
56.250
36.000
+/+
VESA，800 x 600
37.879
60.317
40.000
+/+
VESA，800 x 600
48.077
72.188
50.000
+/+
VESA，800 x 600
46.875
75.000
49.500
+/+
VESA，1024 x 768
48.363
60.004
65.000
-/-
VESA，1024 x 768
56.476
70.069
75.000
-/-
VESA，1024 x 768
60.023
75.029
78.750
+/+
VESA，1152 x 864
67.500
75.000
108.000
+/+
VESA,1280 X 960
60.000
60.000
108.000
+/+
VESA,1280 X 1024
63.981
60.020
108.000
+/+
VESA,1280 X 1024
79.976
75.025
135.000
+/+
VESA，1360 x 768
47.712
60.015
85.500
+/+
VESA, 1366 x 768
47.712
59.790
85.500
+/+
