12
LC display shown on the example of the BA 5000-1 battery pack
Changing the microphone head
To change the microphone head of the SKM 5200:
Different microphone heads ensure suitability for a wide variety of
applications:
Note:
The battery pack is carefully charged using the
− ΔU-method.
For further details, please refer to the user manual of the L 50
charger.
y
6-step LC display for (remaining)
battery pack capacity.
y
Microprocessor-controlled electronics
takes self-discharge of rechargeable
cells into account
y
The maximum capacity of is reduced
due to natural ageing of the cells. The
BA 5000-1 battery pack measures
the maximum capacity and therefore
displays less than 100 % capacity for
older cells – even when they have
been fully charged.
̈ Unscrew the microphone head by
turning it in the direction of the
arrow.
̈
Pull off the microphone head
ƹ
.
̈
Put on the new microphone head.
̈
Screw tight the microphone head by
turning it against the direction
indicated by the arrow.
Model Type Pick-up
pattern SPL
ME 5002 condenser omni 138 dB
ME 5004 condenser cardioid 139 dB
ME 5005 condenser, high feedback
rejection super-cardioid 154 dB
Low-Batt
ƹ
