Unmanaged Switch

SMC-EZ108FDT / SMC-EZ1024FDT

EZ Switch

TM

8 and 24-Port 10/100Mbps Standalone Unmanaged Layer 2 Switches

www.smc.com

The EZ Switch ™ 10/100 provides 8/24 10/100 switching
ports and a slot for an optional fiber uplink. A range of
100Mbps connectors is available, including SC, MTRJ, and
VF-45. It is most ideal for workgroups looking for distance
connection up to 20Km, suitable for environment such as
schools, university campus, and between buildings.

For SMC-EZ108FDT, it also includes a sliding switch in the
rear for VLAN configurations. When turned on, all ports will
automatically be segregated into an individual VLAN. The
uplink will be belong to every VLAN. This is the perfect
solution for workgroups that requires security but at the
same time, still have access to distance servers or back-
bone connection.

FEATURES

Distance connection up to 20Km away with optional
uplink connection

A range of fiber modules to choose from with
SC/ST/VF-45/MT-RJ connectors

High port count for expanding network—max. of 9/17/25 ports

Auto-MDIX ports—no crossover cables required

Rackmountable

No crossover cable required, simply plug and play

Simple VLAN application on the EZ108FDT for easy management

BENEFITS

OVERVIEW
