Assembly Pack Check List (XR895)
Step 1
#89. 3/8" x 7T
Nyloc Nut (2 pcs)
#65.3/8 x 2-1/4
Hex Head Screw (4pcs)
#67. 3/8 x 4
Hex Head Screw (2pcs)
#77.3/8" x 19 x 1.5T
Flat Washer (2pcs)
#84.3/8" x 25 x 1.5T
Flat Washer (4pcs)
Step 2
#99. M5 x 12m/m Phillips
Head Screw (4pcs)
#83. 5/16" x 20 x 1.5T
Curved Washer (2pcs)
#82. 8m/m x 1.5T
Split Washer (2pcs)
#68. 5/16 x 15m/m
Hex Head Screw (8pcs)
#76. 5/16" x 19 x 1.5T
Flat Washer (6pcs)
