ted You can enjoy connected components via the system’s speakers.
DAV-DZ380W/DAV-DZ680W
Portable audio source (not supplied): E
USB device (not supplied): F
DIGITAL MEDIA PORT adapter: G (TDM-iP20 is supplied with United Kingdom models. You can
also use other DIGITAL MEDIA PORT adapters.)
Connecting the other components
CENTER
SUBW OOFE R
HDM I OU T
SPE AKE R
COAXIAL 75 FM
ANTE NNA
DMP ORT
DC5V
0.7A MAX
DIGITAL IN
COAXIAL
OPTICAL
TV
EUR O AV
OUTP UT(TO TV)
EZW -RT1 0
FRONT R
FRONT L
SPEA KER
G DIGITAL MEDIA PORT adapter
(page 88)
To a portable audio source
E Stereo mini-plug cord
(not supplied)
F Connect a USB
device (page 76).
Note
• Connect the DIGITAL MEDIA PORT
adapter so that the V marks are aligned.
When disconnecting, pull out while
pressing .
