Prepare screws (not supplied) that are suitable for the hole on the back of each speaker.
See the illustrations below.
2
Fasten the screws to the wall.
DAV-DZ380W
DAV-DZ680W
30 mm (1
3
/
16
inches)
4 mm (
5
/
32
inch)
Hole on the back of
the speaker
5 mm
(
7 /
32
inch)
10 mm
(
13
/
32
inch)
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
145 mm
(5
3
/
4
inches)
For the center speaker For the other speakers
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
145 mm
(5
3
/
4
inches)
For the center speaker
210 mm
(8
3 /
8
inches)
For the front speakers
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
For the surround speakers
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
