TECHNICAL SPECIFICATIONS SMC6709GL2
PORTS
• 8 auto-MDIX 10BASE-T/ 100BASE-TX RJ-45 ports
• Pre-configured with 1 1000BASE-SX port
• Built-in Network Management
NETWORK INTERFACE
• 10BASE-T: RJ-45 UTP CAT. 3, 4, 5
• 100BASE-TX: RJ-45 UTP CAT. 5
• 1000BASE-SX: SC connector
• Multimode fiber cable; 62.5/125 or 50/125 microns
LEDs
• System: Power
• Port: 10/100, Link/Activity, Duplex/Collision
DIMENSIONS
• 10 x 1.75 x 5.25 in / 25x 38x 13.2 cm
WEIGHT
• 2 lbs / 6 oz
HUMIDITY
• Operating: 10% to 9% (non-condensing)
TEMPERATURE
• Operating: 32 to 113°F / 0° to 45°C
• Storage: -40 to 158°F / -40° to 70°C
WARRANTY
• Limited Lifetime
BUFFER ARCHITECTURE
• 2Mbits
SWITCH BANDWIDTH CAPACITY
• 3.6Gbps
AC INUT
•100 to 240V, 50 to 60Hz
POWER SUPPLY
• Internal, auto-ranging transformer:
100 to 240VAC, 47 to 63Hz
POWER CONSUMPTION
• 19W max. @ 100-240 VAC
MAXIMUM CURRENT
• 0.16A max. @ 110V
SWITCH FEATURES
• Spanning Tree Protocol
• Store-and-Forward
• Flow Control
• Full Duplex: IEEE802.3x
• Half Duplex: back pressure
• VLAN support
• Up to 128 groups; port-based or with 802.1Q
• VLAN tagging, GVRP for automatic VLAN learning
• Class of Service
• Supports two levels of priority
• Broadcast storm control
• Link Aggregation
• Port Mirroring
MANAGEMENT FEATURES
IN-BAND MANAGEMENT
• Telnet, Web-based HTTP, or SNMP manager
Out-of-BAND MANAGEMENT
• RS-232 DB-9 console port Software Loading
• TFTP in-band or Xmodem out-of-band
• MIB Support
• MIB II (RFC 1213), Bridging MIB (RFC 1493), Ethernet-like
MIB (RFC 1643), RMON MIB (RFC 1757)
RMON SUPPORT
• Groups 1, 2, 3, 9 (Statistics, History, Alarm, Event)
STANDARD
• IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet
• IEEE802.1D Spanning Tree Protocol
• IEEE802.1Q VLAN
• IEEE802.1P Priority Tags
• IEEE802.3x Full-Duplex, Flow Control
• SNMP (RFC 1157), RMON (RFC 1757), ARP (RFC 826), IGMP
(RFC 1112), MIB II (RFC 1213), Ethernet-like MIB (RFC 1643),
Bridge MIB (RFC 1493)
COMPLIANCES
CERTIFICATION
• CE MarkEmissions
• FCC Class A, CISPR Class A Immunity
• IEC 1000-4-2/3/4/6
SAFETY
• CSA/NRTL (CSA22.22950 & UL 1950), EN60950 (TUV/GS)
North America
38 Tesla
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/ Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
