23
SPECIFICATIONS
Name Blood Bank Refrigerator
Model MBR-1404G MBR-1404GR
External dimensions W1440 x D830 x H1950 (mm)
Internal dimensions W1320 x D697 x H1500 (mm)
Effective capacity 1287 L
Exterior Painted steel
Interior Painted steel
Door Double layer pair glass/steel plate, Self-closing mechanism, 2 doors
Insulation Rigid polyurethane foamed-in place
Shelf
Hard steel wire on polyethylene coating
12 shelves
-----
Drawer -----
Stainless steel, Handle with card holder
12 drawers
Access port Left side, right side, Inner diameter; 30 mm
Cooling method Forced cool air circulation
Compressor Hermetic type, Output; 300 W
Condenser Fin and tube type
Evaporator Fin and tube type
Refrigerant R-134a
Defrosting Cycle defrost, Forced type, Fully automatic
Temperature controller Electronic control system
High temp. alarm Changeable, Lamp flashing, Buzzer and remote alarm
Low temp. alarm Changeable, Lamp flashing, Buzzer
Door alarm Door alarm lamp ON, Buzzer after delay of 2 minutes
Memory back-up Nonvolatile static memory
Fluorescent lamp White light 40 W x 1 (Glow starter; FG-4P)
Temperature recorder 7-day type
Accessories 1 set of key, 2 sets of bolt
Battery 6 V, 1100 mAh (Ni-MH)
Weight 245 kg 290 kg
Note Design or specifications will be subject to change without notice.
PERFORMANCE
Chamber temperature +4 o C ± 1.5 o C
Usable ambient temperature +5 o C to +35 o C
Power failure alarm duration 24 hours (with the battery full charged)
Maximum pressure 1220 kPa
Noise level 45 dB (A scale)
Rated voltage AC 110 V AC 115 V AC 220 V AC 220 V AC 230 V AC 240 V
Rated frequency 60 Hz 60 Hz 60 Hz 50 Hz 50 Hz 50 Hz
Rated power consumption 350 W 350 W 360 W 390 W 390 W 415 W
Note The unit with CE mark complies with EC directives 89/336/EEC, 93/68/EEC and 73/23/EEC.
