Page 12

REFRIGERATOR COMPONENTS

Inside of front cover

1. Condenser filter:

This filter is to prevent dust from plugging the condenser. Please clean the filter

once a month.

2. Glow starter:

This is for fluorescent light. Use “FG-4P” for replacement.

3. Remote alarm terminal:

Refer to page 15.

4. Spacer (rear side):

This spacer keeps the unit the proper distance from the wall. This spacer is

also available for metal fitting to prevent tipping.

5. Evaporating tray (rear side):

This is for evaporation of the drained water from evaporator.

6. Power switch:

“ ”; ON, “ ”; OFF.

7. Battery switch:

ON/OFF switch of installed battery for power failure alarm. Make sure to turn on

this switch when the unit is in operation.

Note:

Turn off the switch to protect the battery when the unit is not used for long periods.

7 2
