7 DESCRIPTION OF THE CONTROLS
7.1 Front control panel
All of the commands and controls for the hob are found on the front panel.
MODEL 60 CONTROL PANEL
MODEL 70 CONTROL PANEL
MODEL 100 CONTROL PANEL
DESCRIPTION OF THE KNOB
The flame is lit by pressing the knob and simultaneously turning
it anticlockwise to the minimum flame symbol .
To adjust the flame, turn the knob to the zone between
maximum and minimum .
Turn off the flame by turning the knob to position .
ARRANGEMENT OF THE BURNERS – Description of symbols
REAR LEFT
REAR RIGHT
FRONT RIGHT
FRONT LEFT
MIDDLE LEFT
MIDDLE RIGHT
MIDDLE
