Using the Settings
52
PC Input Signal Compatibility Chart
*
:
Corresponding to the VGA signal
Overscan
Normal
Displays a standard size picture.
+1/+2
Allows you to adjust the viewable picture area
size. This is useful for viewing ticker tape or
banners at the top or bottom of the screen.
Not available for PC input.
V Center
(Vertical Center)
Allows you to move the position of the picture up and down in
the window. Available only in Wide Zoom and Zoom modes.
Press
V/v
and press
to choose a correction between +10
and –10 (Zoom mode), and +10 and –10 (Wide Zoom mode).
H Center
(Horizontal
Center)
Allows you to move the position of the picture left and right in
the window. This function allows for horizontal adjustment of
the picture being displayed.
Phase
Adjust the horizontal stripes.
Available only for PC input.
Pitch
Adjust the vertical stripes.
Available only for PC input.
Reset
Clear
Wide Mode, V
Center
,
H
Center
,
Phase
and
Pitch
adjustments you made to the factory settings.
Available only for PC input.
Option
Description
z
4:3 Default and
Overscan are not
available for PC Input.
z
H Center feature is
useful if TV is
connected to game
equipment.
z
The setting of V Center
and H Center can be
between
−
50 and + 50
for PC input.
Resolution
Horizontal frequency
(kHz)
Vertical
frequency (Hz)
VESA standard
Signals
Horizontal
(Pixel)
×
Vertical
(Line)
VGA
640
Ч
480
31.5
60
–*
640
Ч
480
37.9
73
✔
640
Ч
480
37.5
75
✔
720
Ч
400
31.5
70
–*
SVGA
800
Ч
600
35.2
56
✔
800
Ч
600
37.9
60
✔
800
Ч
600
46.9
75
✔
800
Ч
600
48.1
72
✔
848
Ч
480
31.0
60
✔
XGA
1024
Ч
768
48.4
60
✔
1024
Ч
768
56.5
70
✔
1024
Ч
768
60
75
✔
WXGA
1280
Ч
768
47.4
60
✔
1280
Ч
768
47.8
60
✔
1280
Ч
768
60.3
75
✔
1360
Ч
768
47.7
60
✔
This TV does not support Sync on Green or Composite Sync.
If a signal other than in the above chart is input, it may not be displayed properly or may not be displayed as you set.
Using the Vertical frequency (Hz) of the personal computer at 60 is recommended.
