Bundling the connecting cables, Adjusting the viewing angle of the tv – Sony WEGA KLV S23A10 User Manual
Page 12

Introducing the TV
12
Bundling the
Connecting Cables
You can bundle the connecting cables as illustrated below.
1
Bundle the connecting cables.
2
Route the connecting cables through the hook.
Adjusting the
Viewing Angle of the
TV
This TV can be adjusted within the angles shown below.
Do not bundle the AC power cord for KLV-S23A10 in the stand with
other connecting cables.
KLV-S19A10
KLV-S23A10
When adjusting the angle, hold the stand with one
hand to avoid slipping or tipping the stand.
Adjust the angle back and forth
(tilt)
3°
8°
Adjust the angle left and right
(swivel)
Right view
Front
Top view
Front
15°
15°
15°
15°
